High-Conductivity Signal Wire AWG24 2 m – FPS

The FPS Softair W19C is a high-conductivity signal wire, entirely manufactured in Italy and specifically developed for electronic circuits in AEG airsoft replicas, including MOSFETs and electronic control units. Its flexible construction, featuring 19 chrome-plated pure copper strands and FEP insulation, provides a thin cable designed for high-temperature resistance and easy routing through confined gearbox spaces.

Features and technical specifications

• Manufacturer: FPS Softair
• Model: W19C
• Manufacturer part number: W19C
• Type: high-conductivity electrical signal wire
• Wire gauge: AWG24
• Length: 2 metres
• Outer diameter: 1.00 mm
• Conductor: 19 chrome-plated pure copper strands
• Insulation: FEP (fluorinated ethylene propylene)
• Claimed maximum operating temperature: 250°C
• Construction: flexible, multi-strand conductor
• Applications: signal wiring for MOSFETs, electronic control units and AEG control circuits
• Compatibility: AEG electrical systems, including Tokyo Marui-type configurations, with properly installed wiring
• Manufacturing origin: 100% Made in Italy

The small outer diameter and flexible strands make it easier to route the wire through internal gearbox channels, helping keep wiring organised and clear of moving mechanical components, including the motor pinion.

The W19C is intended for signal and control connections rather than the main high-current wiring used to power the motor.
